Germany GW IV b ( GRASSHOPPER ) IeFH18/1 L28

Alkett prototype 10.5cm leFH 18/40/2 L/28 (Sf) auf Geschüetzwagen III/IV artillery SPG The Krupp-Gruson design was called the 10.5cm leFH 18/1 L/28 auf Waffenträger IVb. The Alkett Rheinmetall-Borsig design was given the name 10.5cm leFH 18/40/2 L/28 (Sf) auf Geschüetzwagen III/IV. The German word Waffenträger means ‘weapon carrier’ and Geschüetzwagen translates to ‘gun vehicle’ (it was often abbreviated to just GW). Both words are appropriate to describe these vehicle’s function. It was also called the 10.5cm leFh/40/2 (Sf) Geschutzwagen PzIVb, or 10.5cm leFh/40/2 (Sf) GW PzIVb or 10.5cm le.F.H. 18/40/2 L/28 (Sf) auf GW III/IV. The letters (SF) stand for ‘Selbstfahrlafette’ – self-propelled carriage. The abbreviation leFH stands for the German words ‘leichte FeldHaubitze’ which, translated, means light field howitzer. To remove the turret and gun on the Krupp-Gruson design, a large folding metal gantry was mounted on the rear of the vehicle. When it was folded down the long metal arms were stowed on top of the track guards. This vehicle was given the nickname of the Heuschrecke, the Grasshopper, as the folded metal arms looked like the legs of a grasshopper. It is easy to tell the two designs apart. The Alkett Rheinmetall-Borsig 10.5cm weapon carrier does not have any external folding metal struts on top of its track guards unlike the Krupp-Gruson design. The 10.5cm LeFH 18/40/2 L/28 light field howitzer’s carriage rails and wheels were stowed at the rear of the vehicle on the outside. When the gun crew wanted to dismount the howitzer from the vehicle to use it as conventional artillery gun on the ground, they would unlock the gun from its mount and use a jack to lift it up and off. The armored superstructure of the turret is hinged at the front to allow it to be folded forward to give more room to the gun crew during the removal procedure. The carriage, carriage wheels, and rear rails would then be reattached. A ramp down from the top of the vehicle would be fitted and a manual block and tackle winch system were used to lower the gun down to the ground. The reverse procedure would be used to remount the gun on top of the vehicle. The howitzer could be fired from on top of the vehicle like a normal self-propelled gun. It could traverse through 360 degrees, as it was mounted on a turntable gun platform that was counter sunk into the top of the tank chassis. There was no top to the turret. There were a few disadvantages of an open topped vehicle. The crew was exposed to the elements and were also at risk of injury from enemy thrown hand grenades, mortars and shrapnel from air burst enemy shells. A canvas tarpaulin rain cover was produced to give some protection from the elements.
